欧式套环 | 规格(mm) | 尺寸(mm) | ||||
A | B | C | D | E | ||
TKDSJ-2036-001 | 4 | 25 | 20 | 11 | 7 | 4 |
TKDSJ-2036-002 | 5 | 31 | 24 | 15 | 8 | 5 |
TKDSJ-2036-003 | 6 | 37 | 29 | 18 | 10 | 6 |
TKDSJ-2036-004 | 7 | 44 | 34 | 22 | 11 | 7 |
TKDSJ-2036-005 | 8 | 51 | 38 | 24 | 12 | 8 |
TKDSJ-2036-006 | 10 | 64 | 46 | 30 | 14 | 10 |
TKDSJ-2036-007 | 12 | 76 | 57 | 38 | 18 | 12 |
TKDSJ-2036-008 | 14 | 82 | 60 | 40 | 20 | 14 |
TKDSJ-2036-009 | 16 | 89 | 64 | 42 | 22 | 16 |
TKDSJ-2036-010 | 18 | 102 | 69 | 45 | 26 | 18 |
TKDSJ-2036-011 | 20 | 115 | 79 | 51 | 28 | 20 |
TKDSJ-2036-012 | 22 | 127 | 89 | 54 | 30 | 22 |
TKDSJ-2036-013 | 24 | 140 | 102 | 64 | 34 | 26 |
TKDSJ-2036-014 | 26 | 152 | 105 | 64 | 34 | 28 |
TKDSJ-2036-015 | 28 | 165 | 115 | 73 | 38 | 30 |
TKDSJ-2036-016 | 30 | 178 | 121 | 79 | 44 | 32 |
TKDSJ-2036-017 | 32 | 203 | 133 | 93 | 46 | 34 |
